Mükemmel kesim için güçlü gövde
Uzun ömür için sertleştirilmiş ve taşlanmış bıçaklar
Salıncak kirişli üst tabla ile kanıtlanmış ve sağlam tasarım
CNC kontrollü motorlu bıçak aralığı ayarı
CE standartları ve güvenlik
Ekonomik ve mükemmel kesme performansının birleşimi
Cybelec'in kullanıcı dostu CNC dokunmatik ekran kontrol ünitesi
Otomatik yukarı salınımlı arka gösterge
Sac destek kolları
Demir bilyalı aktarma tablaları ve ön destek kolları
Aydınlatma ve gölge çizgisi
Optional Equipments
Cyb Touch 8 Control Unit-Touch screen CE-Norm Sheet Slider at rear Motorized Blade gap adjustment Ball screw back gauge 1000 mm 1 mt. Flip up finger guards with flexi glass 1 Squaring arm L= 1500 mm, with scale & T-Slot 2 Support arms L=1000 mm, with T-Slot Ball Transfer Tables Stroke Counter from control unit Rubber pads for holddowns Illumination & Shadow wire Top 2 side & Bottom blades with 4 side
Standard Equipments
Light Curtains for Finger Protection P neumatic thin sheet support device add. Support Arms L= 2 m with vertical support for each add. Support Arms L= 3 m (1 pc.) with vertical support Extension Support Arms L= 2 m (1 pc.) with vertical support Extention Support Arms L= 3 m (1 pc.) with vertical support Extension Squaring Arm L= 2 m (1 pc.) with vertical support Extension Squaring Arm L= 3 m (1 pc.) with vertical support Ball integrated squaring arms or support arms Adjustable Angle stop 0-180° Laser Cutting Line Spare-Blades: Standard Top and Bottom Blade (1 set) Oil Coolant Special Colour Oil heater
Strong and precise back gauge Motorized blade gap adjustment by control unit Back covers with light barriers Sheet slider at the back
Hold down cylinders
Cybelec CybTouch 8
Better Cutting • Automatic calculations of the shear functions upon material specifications • Automatic blade gap • Automatic cutting angle • Automatic cutting length • Automatic back gauge correction • Automatic back gauge foldaway • Anti-twist management • 2/3-position sheet support • Return to sender function (RTS) • Front or back gauge management • Parking position (foldaway function) • Hold-downs pressure management • System pressure management • Sheet position offset, allowing to cut in the middle Powerful • Large cutting sequences and programs can be memorized • Easy communicationvia wireless connection to a laptop computer • Over 10 languages available Customer Benefits Very simple to use with intuitive touch screen programming Higher quality and productivity increase Powerful features for maximum output Easy Operating • High-contrast touchscreen, with vivid colors • Simple pages, large keys, clear display with all the information the operator needs • Intuitive and user-friendly interface • Complete programming of parts in seconds • Quick set up of the machine with the EasyCut page. • Contextual help and warning pop-up
